Glass Skylight GXL
Technical Information
Technical Drawings
Coming Soon!
Basic Common Sizes
| Internal Opening | Single Glazed | Double Glazed |
| Dimension | Product Code | Product Code |
| 1000 x 1500mm | GXL100150AU-SG | GXL100150AU-DG |
| 1000 x 2000mm | GXL100200AU-SG | GXL100200AU-DG |
| 1000 x 2500mm | GXL100250AU-SG | GXL100250AU-DG |
| 1000 x 3000mm | GXL100300AU-SG | GXL100300AU-DG |
| 1000 x 3500mm | GXL100350AU-SG | GXL100350AU-DG |
| 1000 x 4000mm | GXL100400AU-SG | GXL100400AU-DG |
| 1000 x 4500mm | GXL100450AU-SG | GXL100450AU-DG |
| 1000 x 5000mm | GXL100500AU-SG | GXL100500AU-DG |
| 1500 x 1500mm | GXL150150AU-SG | GXL150150AU-DG |
| 1500 x 2000mm | GXL150200AU-SG | GXL150200AU-DG |
| 1500 x 2500mm | GXL150250AU-SG | GXL150250AU-DG |
| 1500 x 3000mm | GXL150300AU-SG | GXL150300AU-DG |
| 1500 x 3500mm | GXL150350AU-SG | GXL150350AU-DG |
| 1500 x 4000mm | GXL150400AU-SG | GXL150400AU-DG |
| 1500 x 4500mm | GXL150450AU-SG | GXL150450AU-DG |
| 1500 x 5000mm | GXL150500AU-SG | GXL150500AU-DG |
| 2000 x 2000mm | GXL200200AU-SG | GXL200200AU-DG |
| 2000 x 2500mm | GXL200250AU-SG | GXL200250AU-DG |
| 2000 x 3000mm | GXL200300AU-SG | GXL200300AU-DG |
| 2000 x 3500mm | GXL200350AU-SG | GXL200350AU-DG |
| 2000 x 4000mm | GXL200400AU-SG | GXL200400AU-DG |
| 2000 x 4500mm | GXL200450AU-SG | GXL200450AU-DG |
| 2000 x 5000mm | GXL200500AU-SG | GXL200500AU-DG |
| 2500 x 2500mm | GXL250250AU-SG | GXL250250AU-DG |
| 2500 x 3000mm | GXL250300AU-SG | GXL250300AU-DG |
| 2500 x 3500mm | GXL250350AU-SG | GXL250350AU-DG |
| 2500 x 4000mm | GXL250400AU-SG | GXL250400AU-DG |
| 2500 x 4500mm | GXL250450AU-SG | GXL250450AU-DG |
| 2500 x 5000mm | GXL250500AU-SG | GXL250500AU-DG |
Maintenance & Repair
Skylights should be inspected at least once per year and any build up of leaves and rubbish be removed from around the skylight. Depending on the severity of the problem, this may be needed to be performed more often.
The Skyspan skylight is normally cleaned by the elements. At least once per year, wipe over with soap and water and a nonabrasive sponge. Avoid using solvents and thinners. Dust and wipe over to ensure that any build up or caked dust is removed which could prematurely cause corrosion. Repeat as often as needed for each individual location.
Installation Instructions
Coming Soon!
Assembly & Packing Time
20 - 25 Working Days
Description
The Skyspan Large Glass Skylight is the pinnacle of fixed Skylights. Our Glass Skylight XL gives the freedom to create a unmatched statement of architectural beauty that is deserved by the most prestige of buildings. The large single pane of glass without the usual hindrance of mullions provides an unblemished view to the outdoors, elevating the interior feel to that of the extraordinary.
Many years of product development and improvements sets apart the Skyspan Glass Skylight XL as not only producing the visual wow factor but also as a product you can trust by exceeding all compliance requirements.
Australian roof types including Corrugated, Metaldecks, Tile Roofs and Concrete Roofs. Suitable for any room where structurally compatible.
